Channel Frame Economy Dump 14K

Trailers - Hydraulic Dump

Print

Channel Frame Economy Dump 14K

Hydraulic Dump

Request More Info

Model

Axle Description

Tire Size

GAWR

GVWR

CHANNEL FRAME ECONOMY DUMP 14K

14x83" DE14

7000#

14000#

Standard Equipment

ST235/80R/16 LRE Tires on 8-Hole
2-7000# Dexter Axles w/Electric Brakes
Axles 1/2 Cambered w/EZ Lube Hubs
2 5/16" DEMCO Easy Latch Adjustable 5/Position Coupler
7000# Drop Leg Jack
HD Diamond Plate Fender (Double Broke)
Width: 83" Inside Box
Break Away Unit w/Charger
DOT Reflective Tape
Primed & Painted Underside
Dual Action Swing Out Doors/1 Piece Spreader Gate
Slide-N Ramp 6' Channel
Spare Rack
Sealed Flush Mount LED Lights
Wiring Harness
Lockable Battery/Pump Box
Crank Style Roll Tarp
Rear Stabalizer Stands
Color: Black Only

Options

Spare ST235/80R/16 LRE on 8-Hole
Solar Battery Charger
Economy Production model. No Other Sizes or Options Available

Frame Structure

Frame: 6" Channel
Tongue: 6" Channel
Sides: 24" Tall 10 GA Sheet Metal w/Toprail
Floor: 10 GA Sheet Metal
Toprail: Rigid 3x2x7GA Rectangular Tubing
Dump Body Frame: 4" Channel
Crossmembers: 3" Channel 16" OC

Dump Components

516 Scissor Hoist
Power Up/Power Down/Gravity Down
Control: Pistol Grip w/10' Cord
Safety Prop
Caulked Seams on Dump Body
Deep Cycle 12V Marine Battery
110 Volt-5 Amp Charger
