WIDE DRIVE OVER 14K
| Model | Axle Description | Tire Size | GAWR | GVWR |
|---|---|---|---|---|
| WIDE DRIVE OVER 14K | ||||
| 16x102" WDO 14K | 2 - 7000# Dexter | ST235/80R/16 LRE | 7000# | 14000# |
| 18x102" WDO 14K | 2 - Electric Brakes Nev-R-Adjust | |||
| 20x102" WDO 14K | E-Z Lube - 1/2 Cambered | |||
| 22x102" WDO 14K | ||||
| 24x102" WDO 14K | ||||
| 26x102" WDO 14K | ||||
| 28x102" WDO 14K | ||||
| 30x102" WDO 14K | ||||
| 32x102" WDO 14K |
- Coupler: 2 5/16" Forged Adjustable 5/Position
- Jack: 10000# Drop Leg
- Fenders: Smooth Drive Over w/Center Brace
- Floor: 2" Treated Pine
- Brake: Electric 4 Wheel w/Break Away Unit & Charger
- Sealed Flush Mount LED Lights
- Stake Pockets & Rubrail
- Spare Rack
- 5' Slide-N-Ramps 3" Channel
- Colors: Refer to Chart
- Frame: 6" Channel on 16-24'
- Frame: 8" Channel on 26-32'
- Tongue: 6" Channel Thru 24'
- Tongue: 8" Channel on 26-32'
- Crossmembers: 3" Channel 16" OC
- Front Bumper w/Side Gussets
- Flush Floor w/Side Extensions
- 83" Between Fenders
- 102" Overall to Outside of Extensions
- 2' Treadplate Dovetail
- Floor to Fender Ht. 11" w/6" Frame
- 9" w/8" Frame
- Spare ST235/80R/16 LRE on 8-Hole
- Electric Brake 2nd Axle
- Fold Up 2K Stabalizer Jack
- Pintle Eye Adjustable 35K
- Tread Plate Steel Floor
- Weld-On D-Rings 5/8"
- Self Cleaning Dovetail w/Jumbo Ramps
- Change Length of Treadplate Dovetail to 3' or 4'
- Other Options Available
